Protect against
Over Voltage
Under Voltage
Surges/Spikes
Powerback Surges
Voltage Protector is also called as Power Guard, Safeguard or Automatic Voltage Switcher, which is designed to protect all the voltage sensitive appliances like refrigerators, air conditioners, etc. It can automatically disconnect the mains power once the voltage is out of the normal range, preventing the appliances being damaged due to over voltage or under voltage. Once the input voltage backs to normal range, it will automatically reconnect to the power grid.
The Voltage Protector constantly monitors the voltage on the power line, and if this is out of the allowed range, it disconnects the equipment. In this condition, the Voltage Protector will only reconnect it after certain delay time when the voltage returns to the proper working range. This connection delay is of vital importance for the protection of your refrigeration equipment.
| Specifications | |
| Model No. | 9813 |
| Brand Name | YXST |
|
Operating Voltage |
220VAC |
|
Operating Frequency |
50 Hz-60 Hz |
|
Over Voltage Cut-off |
260VAC (could be customized) |
|
Under Voltage Cut-off |
165VAC (could be customized) |
| Delay Time for Reconnection | 15s~3min adjustable |
|
Output Capacity |
13 Amps , 2860 Watts |
| Standard Package |
Double Blister + Card |
| Warranty | 1 Year |
Ideal for:
All electrical and electronic equipment
Electronic equipment up to 13 amps
Product Feature:
